Operate project
9.2 Controlling graphic objects
TP 270, OP 270, MP 270B (WinCC flexible)
9-16 Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
Procedure
To display the operator note configured for an I/O field:
1. Select the I/O field, e.g.
.
The I/O field is selected. The LED signal of the
HELP
key indicates that an operator note is
available.
2. Press
HELP
to display the operator note.
The operator note is shown in the language currently set on the HMI device. Any operator
note configured for the current screen is shown when you press the key again.
3. Close the Help window with the
ESC
key or by pressing the
HELP
key again.
Note
To view a new operator note, you first need to close the window showing the current
operator note.
See also
Set language (Page 7-12)
9.2 Controlling graphic objects
9.2.1 Button
9.2.1.1 Description
Purpose
A button is a virtual key on the HMI device screen that can have one or more functions.
To Next Page
