Operate project
9.2 Controlling graphic objects
TP 270, OP 270, MP 270B (WinCC flexible)
9-30 Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
3. Hold the <Tab> key pressed until the button to be acknowledged is selected.
4. Press the <Return> button.
9.2.8 Simple alarm view
9.2.8.1 Description
Purpose
On HMI devices which have displays smaller than 6" (e.g. OP 77B), the simple alarm view is
used for displaying and editing of alarms.
Both alarm views can be used on all other HMI devices.
Layout
The display of the simple alarm view depends on the configuration.
• The display shows all current, departed or acknowledged alarms of the selected alarm
classes.
• The number of lines per alarm and the visible lines.
Operating elements
The buttons have the following functions:
Button Function
This button is used to acknowledge an unacknowledged alarm.
This button triggers the function assigned to the "Edit" event for the selected alarm.
Use this button to call the configured operator note for the selected alarm.
