Siemens SIMATIC TP 270 User Manual

Operating recipes
10.5 Displaying recipes
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
10-13
10.5 Displaying recipes
10.5.1 Viewing and editing recipes in Runtime
Introduction
The WinCC flexible ES offers you two configuration options for viewing and editing recipes
and their corresponding data records in Runtime on the HMI device:
• Recipe view
• Recipe screen
Recipe view
The recipe view is a screen object that is configured in the "Screens" editor. You can specify
what operating function the recipe view will have in Runtime.
The recipe view shows recipe data records in tabular form. The recipe view is particularly
useful if data records are small in size or if only a few values are to be modified.
