Technical data
12.2 Technical data
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
12-5
12.2 Technical data
Technical data
Housing MP 270B 10" Keys /
OP 270 10"
MP 270B 10"
Touch /
TP 270 10"
OP 270 6" MP 270B 6"
Touch /
TP 270 6"
External dimensions (W x H)
in mm
483 x 310 335 x 275 308 x 204 212 x 156
Installation cutout (W x H)
in mm
436
+1
x 295
+1
310
+1
x 248
+1
282
+1
x 178
+1
198
+1
x 142
+1
Installation depth 55 mm 59 mm
Degree of protection
Front
Rear panel
IP65/NEMA 4x Indoor/NEMA 12
IP20
Weight Approx. 6 kg Approx. 4,5 kg Approx. 1 kg
Processor
Type 64 bit RISC CPU
Memory MP 270B OP 270 / TP 270
Memory for configuration 4 MB 2 MB
Bulk storage
Slot for CF card e.g. ATA Flash card
Slot for PC card E.g.
• ATA Flash card
• SRAM cards
• NE 2000-compatible Ethernet card
Software
Operating system Microsoft Windows CE
