Technical data
12.1 Dimension drawings
TP 270, OP 270, MP 270B (WinCC flexible)
12-4 Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
12.1.4 Dimensions, OP 270 6"
Unit dimensions
OP 270 6" device dimensions
308
59 6
204
176
280
Side view
Front view
Plan view
Figure 12-4 OP 270 6" dimensions
