Operate project
9.2 Controlling graphic objects
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
9-57
Note
In the event of an emergency, you can override the operation block on the remotely
controlled or currently inactive HMI device by clicking on the user interface five times in
succession or by pressing the <Shift> key five times in succession. Then you may have
to enter a specific (configured) password.
Keys
In operation mode, all keys have the same function as those on the remote HMI device. You
can therefore use the <Tab> key to move from one object to another on the remote screen in
the order of the tab configuration.
Function keys
When you press a function key that has been configured with a function, this function will be
executed in your project.
If you press a function that has
not
been configured with a function in your project, it will
actuate the function key on the remote HMI device.
9.2.20.2 Touch control
Procedure
Touch the desired operating element on the touchscreen of the HMI device.
9.2.20.3 Keyboard control
Procedure
How do I operate the Sm@rtClient view with touch?
• Activate the desired operating element with
TAB
according to the configured tab
sequence on the remote HMI device.
• Move the scroll bars in the desired direction with
CTRL
+ or
CTRL
+ .
• To exit the Sm@rtClient view, display a menu line with
SHIFT
+
CTRL
. Use
ALT
to make a
selection and the corresponding shortcut key for the desired menu command.
