Operate project
9.2 Controlling graphic objects
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
9-59
Behavior
The following events can trigger functions when the project engineer has configured them for
the symbols:
• Click
• Double-click
• Press
• Release
• Enable
• Disabling
Note
The icons from the symbol library can only be operated with a mouse or touch screen.
9.2.21.2 Touch control
Procedure
Touch the symbol on the touch screen of your HMI device.
There is no operator feedback, for example with color changes.
9.2.21.3 Mouse control
Procedure
Click on the symbol with the mouse pointer. The active mouse function is
!
e-establ in
Runtime by a changing cursor icon according to your configuration.
There is no operator feedback, for example with color changes.
