Operating system and configuration
6.2 Windows CE Control Panel
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
6-15
Notice
The screen can still be viewed with a reduced back-lighting.
The back-lighting is reactivated on pressing any key or touching the touchscreen. The
function assigned to that key/button is triggered.
See also
Open Control Panel (Page 6-2)
6.2.10 System
"System" option
The "System" option can be used to define the size of the memory for the DRAM file system
(storage memory). It defines how much memory can be used by the applications. Values can
be modified using a slider control. The standard amount of memory in the DRAM file system
for applications is 0.5 MB.
Figure 6-8 "System Properties" dialog
