Operate project
9.2 Controlling graphic objects
TP 270, OP 270, MP 270B (WinCC flexible)
9-34 Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
Shortcut keys Function
CTRL
+
=
Synchronizes the values of the recipe record currently displayed in the recipe
view with the associated tags.
During synchronization, all values of the recipe record are written to the
associated tags. Then the values are read from the tags and used to update the
values in the recipe view.
CTRL
+
Transfers the recipe record currently displayed in the recipe view, to the
connected PLC.
CTRL
+
Transfers the recipe record currently loaded in the PLC, to the HMI device and
displays it in the recipe view.
9.2.9.4 Mouse and keyboard control
Procedure
Mouse
Click the desired operating element or list entry.
Keyboard
Activate the recipe view with <Tab> according to the tab sequence.
The table below shows the shortcut keys used to control the recipe view.
Shortcut keys Function
<Ctrl+Space> Creates a new recipe record in the recipe displayed in the specified recipe
view. The recipe record values are preset with the values that were
specified as "Basic value" when the recipe was configured.
<Ctrl+Return> Saves the recipe data record currently displayed in the recipe view. The
storage location is determined during configuration in the recipe properties
view.
<Ctrl+*> Saves the recipe record currently displayed in the recipe view under a new
name. The storage location is determined during configuration in the recipe
properties view.
<Ctrl+Del> Deletes the recipe record displayed in the recipe view from the data medium
of the HMI device.
<Ctrl+=> Synchronizes the values of the recipe record currently displayed in the
recipe view with the associated tags.
During synchronization, all values of the recipe record are written to the
associated tags. Then the values are read from the tags and used to update
the values in the recipe view.
