Operating recipes
10.6 Recipe data record administration
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
10-19
Result
The values of the recipe record are transferred to the PLC.
10.6.5 Exporting and importing recipe data records
Introduction
Based on your configuration, you can either export recipe data record to a CSV file or import
data records from a CSV file. The extent to which you can influence these processes is
determined by the project configuration. Various input boxes may be configured on the user
interface:
• Input of the CSV file path
• Selection of the recipe data records for export
• Overwriting an existing CSV file
Export recipe data record
Requirements
Export functions are configured.
Procedure
1. Customize the export settings on the user interface of the HMI device. You can set the
CSV file path, for example.
2. Press the button or the key on the HMI device configured with the "Export recipe records"
function.
Result
The recipe data records are exported to a CSV file.
Note
New data records created in Runtime can be exported to an external file.
