Operate project
9.1 Basic principles of operation
TP 270, OP 270, MP 270B (WinCC flexible)
9-12 Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
Key Function Purpose
Moving the cursor
• Selects the next operable screen object on the right or left,
above or below the current screen object.
• Navigates in the screen object.
HOME
Scrolling back Scrolls one page down.
END
Scrolling up Scrolls one page up.
SHIFT
Shift
(upper/lower case)
Use in key combinations, for example, for switching to
uppercase letters.
F
N
Shift (special character) Use in key combinations for the input of special characters.
Some of the keys contain a blue special character on their
bottom left corners, e.g. the "%" character. In order to input
these characters, press the relevant key in combination with
the special character key shown on the left.
CTRL
General control functions Used in key combinations, for example, for navigating through
trend views.
ALT
General control functions Used in key combinations, for example, for the "Status force"
screen object.
9.1.3.2 Functions of the key combinations
General operation
Navigation
Shortcut keys Function
SHIFT
+
TAB
Selects the previously available screen object in the configured tab sequence.
SHIFT
+
SHIFT
+
SHIFT
+
SHIFT
+
Positions the cursor within a screen object, for example, in an I/O field.
F
N
+
HOME
Jumps to the start of the selection list.
