TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
4-1
Installation and connection
4
4.1 Check shipment
Inventory the contents of the shipment. Check for visible signs of damage which may have
occurred during shipment.
Notice
Do not install damaged parts. If parts are damaged, contact ...
Keep the documentation supplied. This belongs to the HMI device and may be required
when commissioning in the future.
4.2 Installation of the HMI device
4.2.1 Installing the MP 270B Keys or OP 270
Prior to installation
If you want to change the labels on the softkeys, change the labeling strips before installing
the HMI device.
Installation in 19” cabinets/racks
Refer to the information provided by the respective cabinet or rack manufacturer to install the
device in a 19” cabinet/rack.
Installation dimensions of standard 19” cabinets:
• Width: 19" (482.6 mm)
• Height: 7 HE (310 mm)
Secure the HMI device to the rails using four screws
