Siemens SIMATIC TP 270

Plan deployment
3.4 Producing the installation cut-out
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
3-5
Installation cut-out
MP 270B 10" Touch, TP 270 10"
Notice
The following air flow requirements must be maintained following installation:
- 100 mm above the HMI device
- 50 mm below the HMI device
- 15 mm at the sides of the HMI device
When using plug-in boards, ensure sufficient space is provided to insert or remove them.
For installation in a front panel, the MP 270B 10" Touch or TP 270 10" requires an
installation cut-out (WxH) of 310
+1
mm x 248
+1
mm. The thickness of the front panel must
not exceed 6 mm.
MP 270B 6" Touch, TP 270 6"
Notice
The following air flow requirements must be maintained following installation:
- 150 mm above the HMI device
- 100 mm below the HMI device
- 15 mm at the sides of the HMI device
When using plug-in boards, ensure sufficient space is provided to insert or remove them.
For installation in a front panel, the MP 270B 6" Touch or TP 270 6" requires an installation
cut-out (WxH) of 198
+1
mm x 142
+1
mm. The thickness of the front panel must not exceed 6
mm.
