Automatic interconnections
If the option "Generate Block Driver“ is activated in the "Compile Program" dialog,
interconnections that are not yet available but that are necessary will be automatically executed.
Table 2-3 Automatic interconnections
SIMO_CHN SIMODIAG
Input parameter (MODE) Output parameter (OMODE)
In addition to the interconnections, the driver generator automatically generates the
following blocks and connects them with the template:
• OB_DIAG1/ OB_DIAG1_PN
• SIMODIAG
Templates
2.3Using templates
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 33
