Note
For control functions REV, POL, and POS, the appropriate opposite direction or speed is switched
on only after the lock time con󹪝gured in SIMOCODE-DP has elapsed (this is indicated on
output QLTA and the Lock time active display in the Standard view.
4.4.2 INBT2 assignment
Assignment of INBT2_01: SIMOCODE-DP check-back signals
The assignment of bits 0.0-0.7 corresponds to the default con󹪝guration of SIMOCODE-DP and
should not be changed. The signals are available at the corresponding block outputs
(QON1, QOFF, QON2, QOVL, QLTA, QREMOTE, QG_WRN, QG_FLT).
The assignment of bits 1.0 and 1.1 does not correspond to the default con󹪝guration, and
must be completed as required. The signals are available at block outputs QCST and QCTA.
Bits 1.2-1.7 are available for all control functions (except POS), for user-speci󹪝c assignment at
block outputs Q1_2 - Q1_7. They are not evaluated internally by the block.
For control function POS, additional bits 1.2 and 1.3 must be assigned as required. The
signals are available at block outputs Q1_2 and Q1_3.
Bit Meaning Con󹪝guration in PDM / WinSIMOCODE-DP
0.0 Status On1 - QON1 Pro󹪝bus-DP Byte 0 - DP Bit 0.0 Send -> [144] Status On1
0.1 Status O󹪜 - QOFF Pro󹪝bus-DP Byte 0 - DP Bit 0.1 Send -> [145] Status O󹪜
0.2 Status On2 - QON2 Pro󹪝bus-DP Byte 0 - DP Bit 0.2 Send -> [145] Status On2
0.3 Overload warning - QOVL Pro󹪝bus-DP Byte 0 - DP Bit 0.3 Send -> [147] Status overload
warning
0.4 Interlock time active - QLTA Pro󹪝bus-DP Byte 0 - DP Bit 0.4 Send -> [148] Status lock time
active
0.5 Local/Remote - QREMOTE Pro󹪝bus-DP Byte 0 - DP Bit 0.5 Send -> [149] Status Automatic
0.6 General fault - QG_FLT Pro󹪝bus-DP Byte 0 - DP Bit 0.6 Send -> [150] Status general fault
0.7 General fault - QG_WRN Pro󹪝bus-DP Byte 0 - DP Bit 0.7 Send -> [151] Status general fault
1.0 Test operation - QCST Pro󹪝bus-DP Byte 1 - DP Bit 1.0 Send -> [157] Status RMT
1.1 Status cooling time active -
QCTA
Pro󹪝bus-DP Byte 1 - DP Bit 1.1 Send -> [156] Status Cooling time
active
1.2 Only for control function
POS: Status run open - Q1_2
POS: Pro󹪝bus-DP Byte 1 - DP Bit 1.2 Send -> [158] Status run
open
Otherwise: user-speci󹪝c assignment
1.3 Only for control function
POS: Status run closed - Q1_3
POS: Pro󹪝bus-DP Byte 1 - DP Bit 1.3 Send -> [159] Status run
closed
Otherwise: user-speci󹪝c assignment
1.4 Q1_4 user-speci󹪝c assignment
1.5 Q1_5 user-speci󹪝c assignment
SIMO_CHN Function
4.4Description of Parameters
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
56 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
