Output Parameters
Parameter Data type Default setting Meaning
MSG_ACK WORD 16#0 Message acknowledged
MSG_STAT WORD 16#0 Message failure
OMODE DWORD 16#0 Status + MODE
QERR BOOL FALSE 1 = Program error
QGRPERR BOOL FALSE 1 = Group Error
QMODF BOOL FALSE 1 = Module I/O Access Fail‐
ure
QRACKF BOOL FALSE 1 = Rack Error
RACK1ERR BOOL FALSE 1 = DP Slave system failure
RACK2ERR BOOL FALSE 1 = Redundant DP Slave sys‐
tem failure
RDSTATUS WORD 16#00 Status of RDSYSST return
code
RESOUT1 BOOL FALSE Reserved
RESOUT2 WORD 16#0 Reserved
RESOUT3 INT 0 Reserved
Input/Output Parameter
Parameter Data type Default setting Meaning
ACC_ID FALSE BOOL 1 = Accept MODE settings
A.1.1 Description of Parameters
A.1.1.1 OMODE structure
Byte 3 Byte 2 Byte 1 and 0
16#80 Valid data 16#01 First Run in OB1 is exe‐
cuted
MODE input
16#40 Invalid data Module error 16#00 OB100 is executed
16#20 Invalid data Redundancy error
16#00 Invalid data Higher level error
The input value of MODE is passed unchanged into the Low word of OMODE.
See also
Block Parameter Of SIMODIAG (Page85)
Parameter
A.1Block Parameter Of SIMODIAG
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
86 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
