Description
The object lists and the action lists are used to generate the module drivers for these hardware
modules.
The object list contains a unique object identi󹪝cation number for each of these hardware
modules. Each object list is assigned to a particular hardware con󹪝guration.
The action list contains a list of actions. These actions must be executed for the object
identi󹪝cation numbers that appear in the object list. Examples of such actions include:
• Assigning the device address
• Interconnecting the input and output parameters of the driver block
The "Generate Module Driver" function generates the module drivers when the CFC is
compiled.
1.8 Example con󹪝gurations
 SIMOCODE DP
 DP Master system Behind Y-Link Behind IE/PB Link
PN IO (6GK1411-5AB**)
and IE/PB Link HA
(6GK1411-5BB00)
PLC Master DP Mode settings
in Step7 HW con󹪝g
S7-compatible or DPV1 DPV1 (S7-compatible: not rec‐
ommended)
NA
Object selection (GSD/PDM)
in Step7 HW con󹪝g
1. SIEM8069.GSE and DPV1:
Basic Type2 compact
(Page15)
2. SIEM8069.GSE (SIMATIC
PDM) and DPV1: Basic
Type2 compact (Page16)
3. SIEM8069.GSE and S7-
compatible: Basic
Type2 com (Page17)
4. SIEM8069.GSE (SIMATIC
PDM) and S7-compatible:
Basic Type2 com
(Page17)
1. SIEP8031.GSE and Basic
Type 2 compact
(Page19)
2. SIEP8031.GSE (SIMATIC
PDM) and Basic Type 2
compact
IE/PB Link PN IO
1. SIEP8031.GSE and Basic
Type 2 compact
(Page23)
2. SIEP8031.GSE (SIMATIC
PDM) and Basic Type
2 compact (Page23)
IE/PB Link HA
1. SIEP8031.GSE and Basic
Type 2 compact
(Page25)
2. SIEP8031.GSE (SIMATIC
PDM) and Basic Type
2 compact (Page26)
SIMOCODE parameter set‐
tings at Device level (Win-SI‐
MOCODE-DP)
Operating Mode: DPV1,
Data Type: Basic Type 2
Operating Mode: DP Norm,
Data Type: Basic Type 2
Operating Mode: DP Norm,
Data Type: Basic Type 2
Introduction
1.8Example con󹪝gurations
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
14 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
