Messages can be triggered by:
• monitoring of motor current limit values
• SIMOCODE_DP signals
• linkable message input.
• Read/Write data record error
4.1.21 Faceplate actuation
Special signals are generated in the block to actuate the block icon and faceplate. These signals
are SIMO_OVL, SIMO_STAT, VSTATUS, and VSTATUS1.
SIMO_OVL is a binary output, which is set if SIMOCODE is congured as overload (OVL).
Refer AS block parameters in the CFC (Page51).
4.2 Message Texts and Auxiliary Process Values
4.2.1 Message Texts and Auxiliary Process Values
Assignment of message texts and message class to block parameters for rst Alarm_8P
Message Number Block Parameter Text Message Class Can be sup‐
pressed by
1 QCUR_AH $$BlockCom‐
ment$$ Current
HH Alarm
AH MSG_LOCK,
M_SUP_C
2 QCUR_WH $$BlockCom‐
ment$$ Current H
Alarm
WH MSG_LOCK,
M_SUP_C
3 QCUR_WL $$BlockCom‐
ment$$ Current L
Alarm
WL MSG_LOCK,
M_SUP_C
4 QCUR_AL $$BlockCom‐
ment$$ Current LL
Alarm
AL MSG_LOCK,
M_SUP_C
5 QG_WRN $$BlockCom‐
ment$$ General
Warning @4%d@/
@5%d@
S MSG_LOCK,
M_SUP_SIMO
SIMO_CHN Function
4.2Message Texts and Auxiliary Process Values
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 49
