4.5 Block Icon and Faceplate
4.5.1 Block Icons
Picture symbol
① Tagname
② QREMOTE
③ EventState
④ QSIM
⑤ QMAN_AUT
⑥ SIMO_STAT
⑦ Test active (QCST)/Read Failure/Write Failure
⑧ LOCKED
During runtime Read/Write error picture symbol is displayed as shown below:
SIMO_CHN Function
4.5Block Icon and Faceplate
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
60 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
