Parameter S7_string_0 S7_string_1
LOCK_OPT ON REVERSE
SS_POS not act. not act.*
* not act.- Not active
Assignment of AS block parameters contained in the CFC Template POL/DAHL to the I/O elds of
the faceplate
Parameter S7_string_0 S7_string_1
ON1_OP 0 Command=SLOW
OFF_OP 0 Command=OFF
ON2_OP 0 Command=FAST
QON1 0 SLOW
QOFF 0 OFF
QON2 0 FAST
LOCK_OPT ON SLOW
SS_POS not act. not act.*
* not act.- Not active
4.4 Description of Parameters
4.4.1 Control Functions
Active commands depending on control functions OVL, DIR, REV, SOFT, STAR
AUTO_M=0 AUTO_M=1 OVL DIR, STAR,
SOFT
REV
AUTO_ON X Not active 0=O 0=O
1=On 1=Forward / Re‐
verse
AUTO_OPT X Not active Not active 0=Forward
1=Reverse
AUTO_ON1 X Not active Not active 1=Reverse
AUTO_OFF X Not active 1=O 1=O
AUTO_ON2 X Not active 1=On 1=Forward
L_ON1 Not active Not active Not active Not active 1=Reverse
L_OFF Not active Not active Not active 1=O 1=O
L_ON2 Not active Not active Not active 1=On 1=Forward
SIMO_CHN Function
4.4Description of Parameters
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
54 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
