Siemens SIMOCODE DP User Manual

Assignment of AS block parameters contained in the CFC Template OVL to the I/O 󹪝elds of the
faceplate
Parameter S7_string_0 S7_string_1
ON1_OP 0 Command=not act.*
OFF_OP 0 Command=not act.
ON2_OP 0 Command=not act.
QON1 0 not act.
QOFF 0 not act.
QON2 0 not act.
LOCK_OPT not act. not act.
SS_POS not act. not act.
not act.* - Not active
Assignment of AS block parameters contained in CFC Template DIR/SOFT/STAR to the I/O 󹪝elds of
the faceplate
Parameter S7_string_0 S7_string_1
ON1_OP 0 Command=not act.*
OFF_OP 0 Command=OFF
ON2_OP 0 Command=ON
QON1 0 not act.
QOFF 0 OFF
QON2 0 ON
LOCK_OPT ON not act.
SS_POS not act. not act.
* not act.- Not active
Assignment of AS block parameters contained in the CFC Template REV to the I/O 󹪝elds of the
faceplate
Parameter S7_string_0 S7_string_1
ON1_OP 0 Command=REVERSE
OFF_OP 0 Command=OFF
ON2_OP 0 Command=FORWARD
QON1 0 REVERSE
QOFF 0 OFF
QON2 0 FORWARD
SIMO_CHN Function
4.3AS block parameters in the CFC
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 53
