Message Number Block Parameter Text Message Class Can be sup‐
pressed by
6 Reserved
7 Reserved
8 Reserved
The auxiliary process values are assigned as follows:
Auxiliary Process
Value
Block Parameter Meaning
1 BA_NA BATCH name
2 STEP_NO Batch Step Number
3 BA_ID Batch ID
• QMSG_SUP is set for MSG_STAT=21 or MSG_LOCK=1.
• To indicate a general warning or general fault in SIMOCODE-DP, the current diagnostic
information is transferred in the form of auxiliary process values, provided that the required
enable signals are present. By updating this information, the output of messages QG_FLT
and QG_WRN can be delayed (by up to 10 processing cycles maximum).
• The Check-back Signal Test (CST) is derived directly from the SIMOCODE-DP information (DP
1.0 Send).
• A variety of other faults and statuses are available at the SIMO_CHN block, e.g. higher-level
fault, simulation, emergency start, monitoring fault, etc. These are not all indicated.
• Linkable message input SETEXTMSG has therefore been provided, for creating freely
congurable messages. To do this, the input must be linked to the desired output. Since this
gives each SIMOCODE-DP individual message characteristics, the cause of the message must
be dened through input EXTMSGTXT. In addition, a numerical value can be passed through
input EXTMSGVAL. Both of these are output as auxiliary process values with the message.
Refer SIMO_CHN Function Block Inputs/Outputs (Page39).
4.3 AS block parameters in the CFC
Assignment of AS block parameters to the I/O Fields of the faceplate (default):
Parameter S7_shortcut S7_unit S7_string_0 S7_string_1
ADD_F1 AddFct1=OFF AddFct1=ON
ADD_F2 AddFct2=OFF AddFct2=ON
AUTON_OP Mode=MANUAL Mode=AUTO
COOL_T Cooling Time S
COUNT1 COUNT1
COUNT2 COUNT2
CS_UPD 0 DiagData=Update
SIMO_CHN Function
4.3AS block parameters in the CFC
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 51
