Message Number Block Parameter Text Message Class Can be sup‐
pressed by
6 QG_FLT $$BlockCom‐
ment$$ General
Fault @6%d@/
@7%d@/@8%d@
S MSG_LOCK,
M_SUP_SIMO
7 QCST $$BlockCom‐
ment$$ Test (CST)
S MSG_LOCK,
M_SUP_SIMO
8 SETEXTMSG $$BlockCom‐
ment$$ External
Signal @9%s@/
@10%X@
S MSG_LOCK,
M_SUP_EXT
The auxiliary process values are assigned as follows:
Auxiliary Process
Value
Block Parameter Meaning
1 BA_NA BATCH name
2 STEP_NO Batch Step Number
3 BA_ID Batch ID
4 CS_4 Data record 130,
byte 4: General warning additional info 1
5 CS_5 Data record 130,
byte 5: General warning additional info 2
6 CS_6 Data record 130,
byte 6: General fault additional info 1
7 CS_7 Data record 130,
byte 7: General fault additional info 2
8 CS_8 Data record 130,
byte 8: General fault additional info 3
9 EXTMSGTXT Auxiliary process text for freely con󹪝gurable message
10 EXTMSGVAL Numeric auxiliary process value for freely con󹪝gurable
message
Assignment of message texts and message class to block parameters for Second
Alarm_8P
Message Number Block Parameter Text Message Class Can be sup‐
pressed by
1 QERR_RSD,
QERR_RCS
$$BlockComment
$$ SIMOCODE DP
Read Failure
P MSG_LOCK,
EN_RCS, EN_RSD
2 QERR_WSD $$BlockComment
$$ SIMOCODE DP
Write Failure
P MSG_LOCK,
EN_WSD
3 Reserved   
4 Reserved   
5 Reserved   
SIMO_CHN Function
4.2Message Texts and Auxiliary Process Values
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
50 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
