Technical Data
B
B.1 Technical data
Table B-1 Memory space requirements and called blocks per block type for SIMOCODEDP Migration Library V9.1 SP2
Block
1
No.
2
Length of
block in the
load
memory, in
bytes
3
Length of
block in the
work memory,
in bytes
3
Length of in‐
stance data in
the load mem‐
ory, in bytes
4
Length of in‐
stance data in
the work
memory, in
bytes
4
Temporary
memory, in
bytes
5
Blocks called
6
SIMODIAG FB658 3460 2818 756 260 166 SFB35, SFB54,
SFC6, SFC51
SIMO_CHN FB659 15474 13706 1630 702 28 SFB35, SFC58,
SFC59
1
The symbolic designator in the symbol table of the library for the respective function block (FB). It must be unique within the
project.
2
Consists of the type of block (FB) and the number.
3
Memory requirement of program code, once per block type
4
Memory requirement for an instance data block.
5
The memory required for the local data when the block is called in an execution level. This is limited according to the speci󹪝c
CPU. If this amount is exceeded, you must check the setting in the CPU con󹪝guration and redistribute it among the
organization blocks based on the actual requirement.
6
The relevant driver block uses these blocks. They are now located in the user program. They are stored in the same library.
B.2 Header information
Header information of the blocks
This library block contain the following header information:
Table B-2 Header information
Function Block FB no. Name Family Author Version Title
SIMODIAG FB658 SIMODIAG FIELD_DV SIMOCODE 7.1 Diag Block SIMOCODE-DP
SIMO_CHN FB659 SIMO_CHN FIELD_DV SIMOCODE 7.1 CHN Block SIMOCODE-DP
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 99
