Parameter
A
A.1 Block Parameter Of SIMODIAG
Input Parameters
Parameter Data Format Default setting Meaning
DADDR* INT 0 Diagnostic address of the DP
Slave
RST_ERR INT 15 RDSYSST call Enable=15,
Disable=0, Reset=1
EN_DIAG BOOL FALSE 1 = Read System Status In‐
formation
EN_MSG* BOOL TRUE 1 = Enable message
EV_ID* DWORD 16#0 Message ID
LADDR* INT 0 Logical address of module
MODE WORD 16#0 Measuring range coding
RACK_NO* BYTE 16#0 Rack number
RACKF BOOL FALSE 1 = Rack Error
SLOT_NO* BYTE 16#0 Slot number
SUBN_TYP BOOL FALSE 1 = External DP interface
SUBN1_ID BYTE 16#FF ID of Primary DP Master sys‐
tem
SUBN2_ID BYTE 16#FF ID of Redundant DP Master
system
SUBN1ERR BOOL FALSE 1 = DP Master system failure
SUBN2ERR BOOL FALSE 1 = Redundant DP Master
system failure
V1_LINK* BOOL FALSE 1 = Operation behind a Y-
Link DPV1
RUNUPCYC INT 3 Number of cycles for which
all messages are suppressed
RESIN1 BOOL FALSE Reserved
RESIN2 WORD 16#0 Reserved
RESIN3 INT 0 Reserved
* These parameters are not linkable and cannot be connected by user via CFC connection.
Refer SIMODIAG Message Texts and Auxiliary Process Values (Page38)
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 85
