SIMO_CHN Function
4
4.1 Description
4.1.1 Object Name (Type+Number)
FB659
SIMO_CHN Function Block
4.1.2 Calling OBs
The watchdog interrupt OB in which the block is installed (e.g. OB32). Also, in OB100 (see
Startup Response).
4.1.3 Function
The function block is used for operating and monitoring the SIMOCODE-DP motor protection and
control device.
The following 9 control functions are supported:
Table 4-1 Control Function
Sl no. Control functions
1 Overload (OVL)
2 Direct starter (DIR)
3 Reversing starter (REV)
4 Star-delta starter (STAR)
5 Dahlander starter (DAHL)
6 Pole changing starter (POL)
7 Valve (VALVE)
8 Positioner 1-5 (POS)
9 Soft starter (SOFT)
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 39
