A.2 Block Parameter Of SIMO_CHN
Input Parameters
Parameter Data Type Default set‐
ting
Meaning WinCC Tag
ADD_F1 BOOL FALSE operator input: 1=additional
function 1 active
Y
ADD_F2 BOOL FALSE operator input: 1=additional
function 2 active
Y
ADDF1_EN BOOL TRUE ENABLE: 1=operator may input
ADD_F1
N
ADDF2_EN BOOL TRUE ENABLE: 1=operator may input
ADD_F2
N
AUT_L BOOL FALSE Linkable Input for Manual/Auto
Mode
N
AUTO_M BOOL FALSE 1=AUTO_ON1, AUTO_OFF, AU‐
TO_ON2 active 0=AUTO_ON, AU‐
TO_OPT active
N
AUTO_OFF BOOL FALSE AUTO: AUTO_M=1: 1=Close/
Stop/O󹪜
N
AUTO_ON BOOL FALSE AUTO: AUTO_M=0: 0=Close/O󹪜/
Stop, 1=Open/Close/Forward/
Reverse/Fast/Slow/On
N
AUTO_ON1 BOOL FALSE AUTO: AUTO_M=1: 1=Close/
Reverse/Slow
N
AUTO_ON2 BOOL FALSE AUTO: AUTO_M=1: 1=Open/
Forward/Fast/On
N
AUTO_OPT BOOL FALSE AUTO: AUTO_M=0: 0 = Open/
Forward/Fast, 1 = Close/Reverse/
Fast/Slow
N
AUTOP_EN BOOL TRUE ENABLE: 1=operator may input
AUTO
N
BA_EN BOOL FALSE Batch enable Y
BA_ID DWORD 16#0 Batch ID Y
BA_NA STRING[32] - BATCH name Y
CUR_AH REAL 130.0 HH Alarm LIMIT in %Is Y
CUR_AL REAL 70.0 LL Alarm Limit in %Is Y
CUR_MIN REAL 20.0 Discrimination threshold for
monitoring Cur in %Is (CUR_MIN
>=20)
N
CUR_WH REAL 115.0 H Alarm Limit (Warning) in %Is Y
CUR_WL REAL 80.0 L Alarm Limit (Warning) in %Is Y
EM_START* BOOL FALSE SIMOCODE DP 0.4: 1=emergency
start
Y
EN_SD_CS BOOL TRUE 1= enable operator updating of
record 131/130/133
N
Parameter
A.2Block Parameter Of SIMO_CHN
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 87
