Parameter Data Type Default set‐
ting
Meaning WinCC Tag
EN_RCS BOOL TRUE 1= Enable updating of record
130(control/signal data)
Y
EN_RSD BOOL TRUE 1= Enable updating of record
131 (Statistic Data)
Y
EN_WSD BOOL TRUE 1= Enable updating of record
133 (Statistic Data)
Y
EXTMSGTXT STRING[16] - Text of external Message N
EXTMSGVAL DWORD 16#0 external Message Value N
HYS* REAL 3.0 Hysteresis of current, (Hys>=0) Y
I1_0 BOOL FALSE SIMOCODE: DP Receive Bit 1.0 N
I1_1 BOOL FALSE SIMOCODE: DP Receive Bit 1.1 N
I1_2 BOOL FALSE SIMOCODE: DP Receive Bit 1.2 N
I1_3 BOOL FALSE SIMOCODE: DP Receive Bit 1.3 N
I1_4 BOOL FALSE SIMOCODE: DP Receive Bit 1.4 N
I1_5 BOOL FALSE SIMOCODE: DP Receive Bit 1.5 N
I1_6 BOOL FALSE SIMOCODE: DP Receive Bit 1.6 N
I1_7 BOOL FALSE SIMOCODE: DP Receive Bit 1.7 N
I23 WORD 16#0 SIMOCODE: DP Receive Bit 2.0 -
3.7
N
INBT2_01 WORD 16#0 process value DP 0.0-1.7 basic
type 2
N
INBT2_23 WORD 16#0 process value motor current ba‐
sic type 2
N
L_CS_UPD BOOL FALSE linkable input: 0->1: update re‐
cord 130
N
L_OFF BOOL FALSE MANUAL LINKED: 1=Close/
Stop/O󹪜
N
L_ON1 BOOL FALSE MANUAL LINKED: 0->1=Close/
Reverse/Slow
N
L_ON2 BOOL FALSE MANUAL LINKED: 1=Open/
Forward/Fast/On
N
L_RESET BOOL FALSE Linkable Input RESET N
L_SD_UPD BOOL FALSE linkable input: 0->1: update re‐
cord 131
N
L_SIMORESET BOOL FALSE Linkable Input SIMORESET N
LADDR* INT 0 Logical address of module N
LIOP_SEL BOOL FALSE Operating mode: 1=linking;
0=operator active
N
LOCK BOOL FALSE 1=Lock/Lock to SS_POS Y
LOCK_ON BOOL FALSE 1=Lock ON Y
LOCK_OPT BOOL FALSE LOCK_ON=1: 0=ON2, 1=ON1 Y
LOCOP_EN BOOL TRUE ENABLE: 1=operator may input
LOCAL
N
M_SUP_EXT* BOOL FALSE 1=Suppress external Message Y
Parameter
A.2Block Parameter Of SIMO_CHN
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
88 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
