AUTO_M=0 AUTO_M=1 OVL DIR, STAR,
SOFT
REV
ON1_OP Not active Not active Not active Not active 1=Reverse
OFF_OP Not active Not active Not active 1=O 1=O
ON2_OP Not active Not active Not active 1=On 1=Forward
Active commands depending on control functions DAHL, VALVE, POS, POL
AUTO_M=0 AUTO_M=1 DAHL, POL VALVE POS
AUTO_ON X 0=O 0=Close 0=Stop
1=Fast / Slow 1=Open 1=Open / Close
AUTO_OPT X 0 = Fast Not active 0=Open
1 = Slow Not active 1=Close
AUTO_ON1 X 1=Slow Not active 1=Close
AUTO_OFF X 1=O 1=Close 1=Stop
AUTO_ON2 X 1=Fast 1=Open 1=Open
L_ON1 Not active Not active 1=Slow 1=Not active 1=Close
L_OFF Not active Not active 1=O 1=Close 1=Stop
L_ON2 Not active Not active 1=Fast 1=Open 1=Open
ON1_OP Not active Not active 1=Slow 1=Not active 1=Close
OFF_OP Not active Not active 1=O 1=Close 1=Stop
ON2_OP Not active Not active 1=Fast 1=Open 1=Open
Priorities in the block when setting commands
The commands are set in positions 0-10. A command is reset when the associated check-back
signal is present, or an associated equivalent signal, or a higher-level error or general fault occur
in SIMOCODE DP.
0. Restart or higher-level error (QCSF)
1. Local operation or SIMOCODE Overload (OVL) function
2. Reset pending commands
3. Interlocking with LOCK
4. Locking for valve
5. Locking for positioner
6. Interlocking with LOCK_ON and LOCK_OPT
7. AUTO with AUTO_M
8. AUTO
9. MANUAL LINKED
10. MANUAL OPERATOR
SIMO_CHN Function
4.4Description of Parameters
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 55
