Bitpos 15-8 7 6 5 4 3 2 1 0 Control
word
 50 - - - - - - - 1 20481 @Motor_er‐
ror.emf
 50 - - - - - - 1 0 20482 @Mo‐
tor_is_o󹪜.emf
 50 - - - - - 1 0 0 20484 @mo‐
tor_is_on.emf
 50 - - - - 1 0 0 0 20488 @mo‐
tor_is_slow.em
f
           
VALVE 60 - - - - - 0 0 0 24576 @vho_un‐
def.emf
 60 - - - - - - - 1 24577 @VHO_er‐
ror.emf
 60 - - - - - - 1 0 24578 @vho_closed.e
mf
 60 - - - - - 1 0 0 24580 @vho_opened.
emf
           
POS 70 0 0 - - 0 0 0 0 28672 @vho_un‐
def.emf
 70 - - - - - - - 1 28673 @VHO_er‐
ror.emf
 70 - - - - - - 1 0 28674 @vho_un‐
def.emf
 70 - - - - - 1 0 0 28676 @vho_opened.
emf
 70 - - - - 1 0 0 0 28680 @vho_closed.e
mf
 70 0 1 - - - - - 0 28736 @vho_closed.e
mf (blink)
 70 1 0 - - - - - 0 28800 @vho_opened.
emf (blink)
Note
Settings with "-" are ignored.
