SIMPRO-100
SIMPRO-100 Relay Settings Sheets
F
PRIM-2400C 227
F.5.3 Alias Settings
(Hidden when EALIAS = N, ALIAS# > EALIAS
setting are hidden.)
Note: Relay Word bit (space) Alias (space)
Asserted text (space) Alias and text
strings can each be up to 15 text
characters. Asserted and deasserted text
strings are not required. Use NA to
disable setting.
ALIAS1 =
[STARTING MOTOR_STARTING BEGINS ENDS]
ALIAS2 =
[RUNNING MOTOR_RUNNING BEGINS ENDS]
ALIAS3 =
[STOPPED MOTOR_STOPPED BEGINS ENDS]
ALIAS4 =
[JAMTRIP LOAD_JAM_TRIP PICKUP DROPOUT]
ALIAS5 =
[LOSSTRIP LOAD_LOSS_TRIP PICKUP DROPOUT]
ALIAS6 =
[LOSSALRM LOAD_LOSS_ALARM PICKUP DROPOUT]
ALIAS7 =
[4UVBA UNBALNC_I_ALARM PICKUP DROPOUT]
ALIAS8 =
[46UBT UNBALNC_I_ALARM PICKUP DROPOUT]
ALIAS9 =
[49A THERMAL_ALARM PICKUP DROPOUT]
ALIAS10 =
[49T THERMAL_TRIP PICKUP DROPOUT]
ALIAS11 =
[47T PHS_REVRSL_TRIP PICKUP DROPOUT]
ALIAS12 =
[SPEEDSW SPEED_SW_TRIP PICKUP DROPOUT]
ALIAS13 =
[IN2 DIRECT_TRIP_IN PICKUP DROPOUT]
ALIAS14 =
[SPDSTR SPEED_SW_IN PICKUP DROPOUT]
ALIAS15 =
[IN5 EMERGNCY_RSTART PICKUP DROPOUT]
ALIAS16 =
[IN1 MOTOR_BREAKER OPEN CLOSED]
ALIAS17 =
[IN4 ACCESS2 ALLOWED PASSWORD_ONLY]
ALIAS18 =
ALIAS19 =
ALIAS20 =
