When all the settings are entered, the relay
displays the new settings and prompts you for
approval to enable them. Answer Y <ENTER> to
enable the new settings. The relay is disabled for
as long as 5 seconds while it saves the new
settings. The ALARM output b-contact closes
momentarily and the Relay Enabled LED
extinguishes while the relay is disabled.
To change a specific setting, enter the command
shown in Table 6.14.
Table 6.14 SET Command Format
6.8.34 SHOW
(Level 1 or 2)
Use the SHOW command to view relay settings,
serial port settings, and SER settings. SHOW
command options are:
Table 6.15 SHOW Command Options
You may append a setting name to each of the
commands to specify the first setting to display
(e.g., SHO 50P1P displays the relay settings
starting with setting 50P1P). The default is the
first setting.
The SHOW commands display only the enabled
settings. To display all settings, including
disabled/hidden settings, append an A to the
SHOW command (e.g., SHOW A).
6.8.35 STATUS
(Level 1 or 2)
The STATUS command displays the relay
self-test information.
To view a status report, enter the command
STATUS. To view the status report k times, enter
the command STATUS k, where k is a number
between 1 and 32767.
6.8.36 STATUS Command Row &
Column Definitions
Table 6.16 STATUS Command Options
The relay indicates OK or FAIL for each self-test
result. Refer to Section 10.2, page 127 for
self-test thresholds and corrective actions.
SET n s TERSE
Where:
n not used to enter Relay settings
R to enter SER settings
P F to enter front serial port settings
P R to enter rear serial port settings
s
the name of the specific setting you wish to jump
to and begin setting. If "s" is not entered, the relay
starts at the first setting.
TERSE
instructs the relay to skip the settings display
after the last setting. Use this parameter to speed
up the SET command. If you wish to review the
settings before saving, do not use TERSE option.
Command Description
SHOW Show relay settings.
SHO P n Show serial port settings. n specifies
the port (F or R);
n defaults to the active port if not listed.
SHO R Show SER settings.
STA
Command
Row
Column Definitions
FID Firmware identifier string.
CID Firmware checksum identifier.
Offset Measures the dc offset voltages for the
current and voltage channels.
+5V_PS Test the power supply voltage outputs.
-5V_PS
+15V_PS
+28V_PS
TEMP Tests the internal relay temperature.
RAM, ROM,
CR_RAM
(critical RAM),
and EEPROM
Test the relay memory components.
BATTERY Tests the real time clock battery voltage.
RTC Tests the real time clock integrated circuit.
LC_TIME Tests the memory locations where the Motor
Learned Cooling Time data is stored.
TC_START Tests the memory locations where the Motor
Learned Thermal Capacity to Start data is
stored.
