Table 6.4 SIMPRO-100 Serial Port Command
Summary
The serial port command explanations that follow
in the Command Explanations subsection are in
alphabetical order.
6.8 Command
Explanations
Each command explanation lists:
• The command
• The serial port access levels where the
command is available, in parentheses
• An explanation of the command use or
response
For example, you can execute the HELP
command, below, from serial port Access Level 1
or 2.
6.8.1 HELP
(Level 1 or 2)
Use the HELP command to display the available
serial port commands. For more details regarding
a particular command, type HELP CMD, where
CMD is the name of the command you are
interested in.
6.8.2 ACC & 2AC
(Go to Access
Level 1 or 2)
The ACC and 2AC commands provide entry to
the multiple access levels. Different commands
are available at the different access levels as
shown in Table 6.4. Commands ACC and 2AC
are explained together because they operate
similarly.
• ACC moves from Access Level 2 to Access
Level 1
• 2AC moves from Access Level 1 to Access
Level 2
See Section 6.8.27, page 93 for more information
on passwords. The factory default password for
Access Level 2 is 100.
The relay closes the ALARM b-contact for one
second after a successful Level 2 access. If you
make three incorrect password guesses, access
is denied and the ALARM contact closes for one
second.
Event Analysis Commands
1
EVENT View event reports 90
1
HISTORY View event summaries/
histories
91
2
HISTORY R Reset event history data 91
1
SER View sequential events
recorder data
94
2
SER R Reset sequential events
recorder data
94
1
TARGET Display relay element status 96
1
TARGET R Reset target LEDs 97
1
TRIGGER Trigger an event report 97
Motor Data Commands
1
LDP Display load profile data 91
1
LDP D Display load profile buffer
size
91
2
LDP R Reset load profile data 91
1
MOTOR Display motor statistics 92
2
MOTOR R Reset motor statistics 92
1
MSR Display motor start reports 93
1
MSR F Display the format of a motor
start report
93
1
MST Display motor start trend
data
93
2
MST R Reset motor start trend data 93
2
RLP Reset learned motor
parameters
94
Relay Setting Commands
1
SHOW Show/view relay settings 95
2
SET Enter/change relay settings 94
Relay Output Control Commands
2
ANALOG Test analog output 90
2
CON Control remote bit 90
2
PUL Pulse output contact 93
2
STOP Stop motor 96
2
STR Start motor 96
Access
Level
Serial Port
Command
Command Description Page
