SIMPRO-100
Commissioning
7
PRIM-2400C 107
Table 7.7 Analog Output Test
7.3.7 RTD Input Measuring
Accuracy
1. Use the front-panel Set Relay\Relay
Elements\RTD Configuration function or serial
port SHOW command to view the input RTD
Type setting for each RTD input. Connect a
variable resistance to each RTD input in turn.
The temperatures given in Table 7.8 on
page 107 – Table 7.11 on page 108 are based
on the RTD type and the value of the
resistance. Referring to these tables, change
the resistance applied to each input until the
appropriate temperature is displayed.
2. Use the front-panel Meter Values\Thermal &
RTD Data function or serial port METER T
command to view the present temperature
measured by the relay RTD input. The
temperature displayed should be ± 2°C or
± 4°F from the temperature represented by
the variable resistance.
Table 7.8 100-Ohm Platinum RTD Type (RTDs 1 – 12)
Table 7.9 120-Ohm Nickel RTD Type (RTDs 1 – 12)
Desired %
Output
ANALOG
Command
Expected Meter Reading
(0-1 mA Range)
Expected Meter Reading
(0-20 mA Range)
Expected Meter Reading
(4-20 mA Range)
Actual Meter
Reading
0% ANA 0 1 0.0mA 0.0mA 4.0mA
25% ANA 25 1 0.25mA 5.0mA 8.0mA
50% ANA 50 1 0.5mA 10.0mA 12.0mA
75% ANA 75 1 0.75mA 15.0mA 16.0mA
100% ANA 100 1 1.0mA 20.0mA 20.0mA
Resistance
Value
(ohms)
Expected
Temperature
Reading
(°C)
Expected
Temperature
Reading
(°F)
RTD Temperatures
1 2 3 4 5 6 7 8 9 10 11 12
80.31 -50 -58
100.00 0 32
119.39 50 122
138.50 100 212
157.32 150 302
175.84 200 392
190.45 240 464
Resistance
Value (ohms)
Expected
Temperature
Reading
(°C)
Expected
Temperature
Reading
(°F)
RTD Temperatures
1 2 3 4 5 6 7 8 9 10 11 12
86.17 -50 -58
120.00 0 32
157.74 50 122
200.64 100 212
248.95 150 302
303.64 200 392
353.14 240 464
