Siemens SIMPRO-100 - RLP (Level 2); SER (Level 1 or 2); SER R (Level 2); SET (Level 2)

6
ASCII Serial Port Operation
SIMPRO-100
94 PRIM-2400C
6.8.30 RLP
(Level 2)
Use the RLP (Reset Learned Parameters)
command at Access Level 2 to reset the learned
motor parameters. You can reset the learned
motor stopped cooling time and the learned
motor starting time values individually. After a
value is reset, the relay needs five motor starts or
motor stops to learn the parameter. Only use this
command when the relay is initially installed, after
a motor rewind, or after overhaul of the load
equipment.
6.8.31 SER
(Level 1 or 2)
Use the Sequential Events Record (SER)
command to view the SER Report, described in
Chapter 9.6, page 122. Each event record is
stored with a record number, a date, and a time.
You can access SER data by record number or
by date. The most recent record is always record
number 1. The various SER command options
are:
Table 6.11 SER Command Options
The date entries used with the SER command
are dependent on the Date Format setting. If the
Date Format setting equals MDY, then the dates
entered should have the format mm/dd/yyyy. If
the Date Format setting equals YMD, then the
dates entered should have the format
yyyy/mm/dd.
If the requested load profile records do not exist,
the relay responds
No SER Data
.
6.8.32 SER R
(Level 2)
SER R removes the SER data from nonvolatile
memory.
6.8.33 SET
(Level 2)
The SET command allows the user to view or
change the relay settings.
Table 6.12 Serial Port SET Commands
When you issue the SET command, the relay
presents a list of settings one at a time. Enter a
new setting or press <ENTER> to accept the
existing setting. Editing keystrokes are:
Table 6.13 SET Command Editing Keystrokes
The relay checks each entry to ensure that it is
within the setting range. If it is not, an
Out of
Range
message is generated, and the relay
prompts you for the setting again.
Serial Port
Command
Description
SER Display all available SER records.
SER n Display the n most recent SER records,
starting with record n.
SER n1 n2 Display SER records n2 to n1, starting with n2.
SER d1 Display all the SER records made on date d1.
SER d1 d2 Display all the SER records made from d2 to
d1, inclusive, starting with d2.
Command
Settings
Type
Description
SET Relay Protection elements, timers, etc.
SET R SER Sequential Events Recorder
trigger conditions and ALIAS
settings.
SET P n Port Serial port settings for Serial
Port n (n = F or R).
Press Key(s) Results
<ENTER> Retains setting and moves to the next
setting.
^ <ENTER> Returns to previous setting.
< <ENTER> Returns to previous setting category.
> <ENTER> Moves to next setting category.
END <ENTER> Exits editing session, then prompts you
to save the settings.
<CTRL> X Aborts editing session without saving
changes.
