SIMPRO-100
Control Equations & Relay Logic
B
PRIM-2400C 141
Table B.2 Relay Word Bit Definitions for SIMPRO-100
B.4 Control Equations
Control equations combine relay protection and
control elements with logic operators to create
custom protection and control schemes. This
section shows how to set the protection and
control elements (Relay Word bits) in the control
equations.
Control equations are set with combinations of
Relay Word bits to accomplish such functions as:
• Tripping circuit breakers
• Assigning contact inputs to functions
• Operating contact outputs
You can use control equations to create
traditional or advanced custom schemes.
8
LT1
LT2
LT3
LT4
Control equation latch bit results.
RB1
RB2
RB3
RB4
Remote bits 1 – 4.
9
SV1
SV2
SV3
SV4
Control equation variables 1 – 4.
SV1T
SV2T
SV3T
SV4T
Control equation variable 1 – 4 with settable pickup and dropout time delay.
10
IN1
IN2
IN3
IN4
IN5
IN6
Contact inputs IN1 – IN6.
IN7 Contact input IN7. Available only when using SIMPRO-100-RTD External RTD module.
* Reserved for future use.
11
TRIP Contact outputs TRIP, OUT1, OUT2, OUT3, and ALARM.
OUT1
OUT2
OUT3
ALARM
*
*
*
Reserved for future use.
Row Bit Definition
