PRIM-2400C 163
C.7 05h Force Single
Coil Command
The SIMPRO-100 Relay uses this function code
for a variety of data control purposes. Specifically,
you can use it to clear archive records, operate
output contacts, and operate breaker and remote
bit elements.
Table C.8 05h Force Single Coil Command
The command response is identical to the
command request.
The SIMPRO-100 Relay offers the commands
listed in Table C.9 that you can execute using
function code 05h. The command coils are
self-resetting.
Table C.9 Command Coils
C.8 06h Preset Single
Register Command
The SIMPRO-100 Relay uses this function to
allow a Modbus master to write directly to a
database register. If you are accustomed to 4X
references with this function code, for 6-digit
addressing, add 400001 to the standard
database addresses.
The command response is identical to the
command request.
Table C.10 06h Preset Single Register Command
Bytes Field
The Master Request must have the Following Format
1 byte Slave address
1 byte Function code (05h)
2 bytes Coil reference
1 byte Operation code (FF for bit set, 00 for bit clear)
1 byte Placeholder (00)
2 bytes CRC-16 for message
Coil Field
1Start
2Stop
3 Emergency Restart
4 Reset Trip, Targets
Bytes Field
The Master Request must have the Following Format
1 byte Slave address
1 byte Function code (06h)
2 bytes Register address
2 bytes Data
2 bytes CRC-16 for message
