Siemens SIMPRO-100 - A5 C0 Relay Definition Block

D
SIMPRO-PC Compatibility Features
SIMPRO-100
190 PRIM-2400C
D.3 Fast Binary Message
Definitions
In response to the A5C0 request, the relay sends
the block shown in Table D.3.
Table D.3 A5C0 Relay Definition Block
In response to the A5C1 request, the
SIMPRO-100 Relay sends the block shown in
Table D.4.
Data Description
A5C0 Command
48 Length
02 Support two protocols
03 Support three Fast Meter messages
06 Support three status flag commands
A5C1 Fast Meter configuration command
A5D1 Fast Meter command
A5C2 Demand Fast Meter configuration command
A5D2 Demand Fast Meter command
A5C3 Peak Demand Fast Meter configuration
command
A5D3 Peak Demand Fast Meter command
0004 Settings change bit
A5C100000000 Fast Meter configuration message
0004 Settings change bit
A5C200000000 Demand Fast Meter configuration message
0004 Settings change bit
A5C300000000 Peak Demand Fast Meter configuration
message
0004 Settings change bit
444E410D0000 DNA Command
0004 Settings change bit
49440D000000 ID Command
0004 Settings change bit
4341530D0000 CAS Command
0100 SEL protocol, Fast Operate
0002 Modbus protocol
00 Reserved
checksum 1-byte checksum of preceding bytes
Data Description
A5C1 Fast Meter command
xx Response Length in Bytes (specific value of
xx based on relay model, as shown below)
0x6C Base Relay
0x94 Relay with RTDs
0xD0 Relay with voltages
0xF8 Relay with RTDs, voltages
01 One status flag byte
00 Scale factors in Fast Meter message
00 No scale factors
xx # of analog input channels (specific value of
xx based on relay model, as shown below)
09 Base Relay
0D Relay with RTDs
13 Relay with voltages
17 Relay with RTDs, voltages
01 # of samples per channel
0D # of digital banks
0D # of calculation blocks
0004 Analog channel offset
xxxx Time stamp offset (specific value of xxxx
based on relay model, as shown below)
0028 Base Relay
0030 Relay with RTDs
0050 Relay with voltages
0058 Relay with RTDs, voltages
xxxx Digital offset (specific value of xxxx based
on relay model, as shown below)
0030 Base Relay
0038 Relay with RTDs
0058 Relay with voltages
0060 Relay with RTDs, voltages
494100000000 Analog channel name (IA)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494200000000 Analog channel name (IB)
01 Analog channel type
