ASCII Serial Port Operation
SIMPRO-100
88 PRIM-2400C
6.6 Serial Port Access
Levels
The available serial port commands are listed in
Table 6.4. Some commands are not available at
Access Level 1 for security reasons. All
commands are available at Access Level 2.
6.6.1 Access Level 1
Access Level 1 is the lowest access level. The
relay serial ports are initially in Access Level 1
when you energize the relay. If left in Access
Level 2, serial ports automatically return to
Access Level 1 after a settable inactivity period.
When the relay is in Access Level 1, the relay
sends the following prompt when you press
<ENTER> or after a command response is
finished:
=>
The Access Level 1 commands primarily allow
the user to look at information (such as settings
and metering) but not to change it.
6.6.2 Access Level 2
The Access Level 2 commands primarily allow
the user to change relay settings, reset data
buffers, and control relay outputs. If left in Access
Level 2, serial ports automatically return to
Access Level 1 after a settable inactivity period.
All Access Level 1 commands are also available
in Access Level 2.
When the relay is in Access Level 2, the relay
sends the following prompt when you press
<ENTER> or after a command response is
finished:
=>>
6.7 Command Summary
Table 6.4 lists the serial port commands
associated with particular activities. All Access
Level 1 commands are also available in Access
Level 2. The commands are shown in upper-case
letters, but can also be entered with lower-case
letters.
Access
Level
Serial Port
Command
Command Description Page
Serial Port Access Commands
1
HELP Display available commands 89
1
2ACCESS Go to Access Level 2 89
2
ACCESS Go to Access Level 1 89
2
PASSWORD View/change password 93
2
QUIT Go to Access Level 1 93
Relay Self-Test Status Commands
1
STATUS Display relay self-test status 95
2
STATUS R Clear self-test status and
restart relay
96
Relay Clock/Calendar Commands
1
DATE View/change date 90
1
TIME View/change time 97
Meter Data Commands
1
METER Display metering data 91
1
METER D Display demand and peak
demand data
91
1
METER E Display energy metering
data
92
1
METER M Display max/min metering
data
92
1
METER T Display thermal metering
data
92
1
METER RD Reset demand ammeter 92
1
METER RE Reset energy metering 92
1
METER RM Reset max/min metering 92
1
METER RP Reset peak demand
ammeter
92
