D
SIMPRO-PC Compatibility Features
SIMPRO-100
192 PRIM-2400C
Table D.4 A5C0 Relay Definition Block A5C1 Fast
Meter Configuration Block
In response to the A5D1 request, the
SIMPRO-100 Relay sends the block
shown in Table D.5.
Table D.5 A5D1 Fast Meter Data Block
In response to the A5C2 or A5C3 request, the
SIMPRO-100 Relay sends the block shown in
Table D.6.
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
4F5448000000 Analog channel name (OTH)
[Hottest Other RTD Temp.]
00 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
All Versions
00 Reserved
checksum 1-byte checksum of all preceding bytes
Data Description
A5D1 Command
xx Length (specific value of xx based on relay
model, as shown below)
63 bytes Base Relay
71 bytes Relay with RTDs
103 bytes Relay with voltages
111 bytes Relay with RTDs, voltages
1-byte 1 Status Byte
##-bytes Magnitudes in 4-byte IEEE floating point
numbers (specific value of ## based on relay
model, as shown below)
36 bytes Base Relay
76 bytes Relay with voltages
##-bytes Magnitudes in 2-byte integer (specific value f
## based on relay model, as shown below)
8 bytes Relay with RTDs
8-bytes Time stamp
13-bytes 13 Digital banks:
11 Relay Word rows, plus 2 rows for targets
1-byte Reserved
checksum 1-byte checksum of all preceding bytes
Data Description
Data Description
A5C2 or A5C3 Command; Demand (A5C2) or Peak
Demand (A5C3)
xx Length in bytes (specific value of xx based
on relay model)
78 bytes Base Relay
118 bytes Relay with voltages
01 # of status flag bytes
00 Scale factors in meter message
00 # of scale factors
xx # of analog input channels (specific value of
xx based on relay model)
6 Base Relay
10 Relay with voltages
01 # of samples per channel
00 # of digital banks
00 # of calculation blocks
0004 Analog channel offset
xxxx Time stamp offset (specific value of xxxx
based on relay model)
0034 Base Relay
0054 Relay with voltages
FFFF Digital offset
494100000000 Analog channel name (IA)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494200000000 Analog channel name (IB)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494300000000 Analog channel name (IC)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494E00000000 Analog channel name (IN)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
