SIMPRO-100
SIMPRO-PC Compatibility Features
D
PRIM-2400C 193
Table D.6 A5C2/A5C3 Demand/Peak Demand Fast
Meter Configuration Messages
In response to the A5D2 or A5D3 request, the
SIMPRO-100 Relay sends the block shown in
Table D.7.
Table D.7 A5D2/A5D3 Demand/Peak Demand Fast
Meter Message
494700000000 Analog channel name (IG)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
334932000000 Analog channel name (3I2)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
When Voltage Inputs Are Included
50332B000000 Analog channel name (P3+)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
51332B000000 Analog channel name (Q3+)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
533300000000 Analog channel name (S3)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
51332D000000 Analog channel name (Q3-)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
All Versions
00 Reserved
checksum 1-byte checksum of preceding bytes
Data Description
Data Description
A5D2 or A5D3 Command
xx Length (specific value of xx based on relay model)
62 bytes Base Relay
94 bytes Relay with voltages
1-byte 1 Status Byte
xx-bytes Demand/Peak demand quantities in 8-byte IEEE
Floating Point numbers (specific value of xx based
on relay model)
48 bytes Base Relay
80 bytes Relay with voltages
8-bytes Time stamp
1-byte Reserved
1-byte 1-byte checksum of all preceding bytes
