8.2 Tabular overview of the parameters
8.2.1 Overview of initialization parameters 1 to 5
Introduction
Parameters 1 to 5 are the same for all versions of the positioner. These parameters are used
to adjust the positioner to the actuator. Normally, setting these parameters is sufficient to be
able to operate the positioner on an actuator.
If you want to get to know all details of the positioner, gradually try out the effects of the
remaining parameters by systematic testing.
Note
Factory-set parameter values are printed in bold in the following table.
Overview
Parameter Function Parameter values Unit
1.YFCT Type of actuator Normal Inverted
Part-turn actuator turn -turn
Linear actuator WAY -WAY
Linear actuator - carrier pin on actuator spindle FWAY -FWAY
Linear actuator - external linear potentiometer
(e.g. with cylinder drives)
LWAY -LWAY
Part-turn actuator with NCS/iNCS ncSt -ncSt
Linear actuator with NCS ncSL -ncSL
Linear actuator with NCS/iNCS and lever ncSLL -ncLL
2.YAGL Rated angle of rotation of positioner shaft
1)
33° Degrees
90°
3.YWAY
2)
Range of stroke (optional setting)
3)
OFF mm
5 | 10 | 15 | 20
(Short lever 33°, range of stroke 5 mm to
20 mm)
25 | 30 | 35
(Short lever 90°, range of stroke 25 mm to
35 mm)
40 | 50 | 60 | 70 | 90 | 110 | 130
(Long lever 90°, range of stroke 40 mm to
130 mm)
4.INITA Initialization (automatic) NOINI | no / ###.# | Strt
5.INITM Initialization (manual) NOINI | no / ###.# | Strt
Parameter assignment
8.2 Tabular overview of the parameters
SIPART PS2 with PROFIBUS PA
134 Operating Instructions, 05/2019, A5E00127926-AC
