Siemens SIPART PS2 User Manual

Rated conditions
● Storage
-25 °C ... 80 °C (-13 °F ... 176 °F), 75% at 25 °C (77 °F),
without condensation
● Temperature
-25 °C ... 80 °C (-13 °F ... 176 °F), 75% at 25 °C (77 °F),
without condensation
● Operation
0 °C to 50 °C (32 °F ... 122 °F), 75% at 25 °C (77 °F), without
condensation
Construction
Weight Approx. 8.5 kg
Enclosure material 19" slide-in module, 2HM, aluminum
Number of channels, basic electronics 5 / 10 / 15
Technical specifications for the controller unit is available at Controller (Page 282).
Electrical specifications
Electrical connection PA bus: LEMO
Field: 50-pin male connector Burndy B50-f / 19-f /8-m, 50-pin
socket connector Burndy B50
Auxiliary energy supply Bus-powered
Bus voltage 9 ... 32 V
Current consumption 10.5 mA ± 10% per channel
Fault current 0 mA
Technical specifications for position feedback is available at Position feedback module
(Page 291).
Technical specifications for communication is available at Communication (Page 288).
F.5 Scope of delivery of remote control electronics
Description Article number
19" slide-in module as 4 to 20 mA version, aluminum, 3 channels, non-Ex A5E00151560
SIPART PS2 without basic electronics, single-acting, polycarbonate enclosure,
non-Ex
6DR5910-...
Positioner with remote control electronics
F.5 Scope of delivery of remote control electronics
SIPART PS2 with PROFIBUS PA
360 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
