01 Lower limit reached
10 Upper limit reached
11 Value is constant.
The meaning of the sub-status depends on whether the condensed status is activated or not.
The sub-status is therefore specified separately for both the cases.
9.3.3.4 Sub-status for deactivated condensed status
Bit Name profile German name
7 6 5 4 3 2 1 0
0 0 0 0 0 0 x x Bad, non specific Schlecht
0 0 0 0 0 1 x x Bad, configuration error Schlecht, Konfigurationsfehler
0 0 0 0 1 0 x x Bad, not connected Schlecht, keine Verbindung
0 0 0 0 1 1 x x Bad, device failure Schlecht, Gerätefehler
0 0 0 1 0 0 x x Bad, sensor failure Schlecht, Sensorfehler
0 0 0 1 1 1 x x Bad, out of service Schlecht, Außer Betrieb
0 1 0 0 0 0 x x Uncertain, non specific Unsicher
0 1 0 1 0 0 x x Uncertain, sensor conversion not accurate Unsicher, Wert ungenau
0 1 0 1 1 1 x x Uncertain, configuration error Unsicher, Konfigurationsfehler
0 1 1 0 0 0 x x Uncertain, simulated value Unsicher, Simulationswert
1 0 0 0 0 0 x x Good, ok Gut, Ok
1 0 0 0 0 1 x x Good, update event Gut, Aktiver Blockalarm
1 0 1 0 0 1 x x Good, maintenance required Gut, Instandhaltungsbedarf
1 1 0 0 0 0 x x Good (Cascade), ok Gut (Kaskade), Ok
1 1 0 0 0 1 x x Good (Cascade), initialisation acknowl‐
edged
Gut (Kaskade), Initialisierung bestätigt
1 1 0 0 1 0 x x Good (Cascade), initialisation request Gut (Kaskade), Initialisierung angefordert
1 1 0 0 1 1 x x Good (Cascade), not invited Gut (Kaskade), Nicht eingeladen
1 1 0 1 1 0 x x Good (Cascade), local override Gut (Kaskade), Vor-Ort-Bedienung
1 1 1 0 0 0 x x Good (Cascade), initiate fail safe Gut (Kaskade), Sicherheitsstellung anfah‐
ren
9.3.3.5 Sub-status for activated condensed status
Bits Name Group
7 6 5 4 3 2 1 0 Profile German
0 0 1 0 0 1 x x Bad, maintenance alarm Schlecht, Instandhaltungsalarm M
0 0 1 0 1 0 x x Bad, process related, no mainte‐
nance
Schlecht, Prozess-Störung, kein
Wartungsbedarf
P
0 0 1 1 1 1 x x Bad, function check /local override;
value not usable
Schlecht, Funktion überprüfen /
Handbetrieb
F
0 1 1 0 1 0 x x Uncertain, maintenance demand Uncertain, maintenance demand M
Functions/operations using PROFIBUS PA
9.3 Cyclic data transfer
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 227

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
