L2.FACT1 - Factor 1
Adjustment range: 0.1 ... 40.0
Purpose: Use this sub-parameter to set the factor for formation of threshold 1.
Set the factor in a range from '0.1' to '40.0'. The threshold is the
product of 'L1.LIMIT' and 'L2.FACT1'.
The threshold 1 message is displayed when threshold 1 is excee‐
ded. This message is only output if threshold 2 or 3 is not exceeded
at the same time. The process to activate and display this message
is described in the 'XDIAG' parameter.
Factory setting: 1.0
L3.FACT2 - Factor 2
Adjustment range: 0.1 ... 40.0
Purpose: Use this sub-parameter to set the factor for formation of threshold 2.
Set the factor in a range from '0.1' to '40.0'. The threshold is the
product of 'L1.LIMIT' and 'L3.FACT2'.
The threshold 2 message is displayed when threshold 2 is excee‐
ded. This message is only output if threshold 3 is not exceeded at
the same time. The process to activate and display this message is
described in the 'XDIAG' parameter.
Factory setting: 2.0
L4.FACT3 - Factor 3
Adjustment range: 0.1 ... 40.0
Purpose: Use this sub-parameter to set the factor for formation of threshold 3.
Set the factor in a range from '0.1' to '40.0'. The threshold is the
product of 'L1.LIMIT' and 'L4.FACT3'.
The threshold 3 message is displayed when threshold 3 is excee‐
ded. The process to activate and display this message is described
in the 'XDIAG' parameter.
Factory setting: 5.0
8.3.3.11 Monitoring of number of changes in direction 'O.\\DCHG'
O. DCHG - Monitoring of number of changes in direction
Condition: The '50.XDIAG' Activation of extended diagnostics (Page 160) pa‐
rameter is set to 'On1', 'On2' or 'On3'.
Possible settings: OFF
On
Parameter assignment
8.3 Description of parameters
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 183
