5.2.4.5 M12 connector for connecting the SIA module 6DR4004-6G /-8G (-Z D56)
You have a positioner with order suffix -Z order code D56. In this version of the positioner, the
M12 connector is used to electrically connect the outputs of the SIA module.
Table 5-5 Assignment diagram
Alarm output terminal Pole designation
41 (+) 1 - Brown
52 (-) 4 - Black
42 (-) 3 - Blue
51 (+) 2 - White
5.2.4.6 M12 connector for connecting the mechanical limit switch module 6DR4004-6K (-Z D57)
You have a positioner with order suffix -Z order code D57. In this version of the positioner, the
M12 connector is used to electrically connect the outputs of the mechanical limit switch module.
Table 5-6 Assignment diagram
Alarm output terminal Pole designation
41 (+) 1 - Brown
52 (-) 4 - Black
42 (-) 3 - Blue
51 (+) 2 - White
5.3 Pneumatic connection
5.3.1 Basic safety instructions for the pneumatic connection
WARNING
Pneumatic auxiliary power
For safety reasons, the pneumatic auxiliary power supply can be fed after installation only if
the positioner is switched to "P-Manual mode" when an electrical signal is present. This
operating mode is preset in the delivery state.
Note
Specifications regarding air quality
Observe the specifications regarding the air quality, see section "Technical specifications
> Pneumatic data (Page 282)".
Connect
5.3 Pneumatic connection
SIPART PS2 with PROFIBUS PA
92 Operating Instructions, 05/2019, A5E00127926-AC
