Siemens SIPART PS2 User Manual

Meaning Symbols
No diagnostics check
No functional restrictions known. The field device does not support ad‐
ditional diagnostics information.
Test mode (background color of diagnostics icon)
The device is in local test mode. All the displayed information or diag‐
nostics may be simulated. The information transferred to the automation
systems (process values and status) may also be simulated.
9.2.4.2 Device diagnostics
"Diagnostics" tab
In this "Diagnostics" tab you can find:
● Communication
● Device status
● Last test
● Message text
"Messages" tab
In this "Messages" tab you can find:
● Device status
● Checkback
● Limit status (group signal of all three-stage diagnostics events, detailed diagnostics events
can be found under the "Device diagnostics" tab)
● Binary input 1
● Binary input 2
"Device diagnostics" tab
In this "Device diagnostics" tab you can find:
● Device diagnostics 1
● Device diagnostics 2
● Quality
● Status
Functions/operations using PROFIBUS PA
9.2 Acyclic data transfer
SIPART PS2 with PROFIBUS PA
206 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
