Siemens SIPART PS2 User Manual

1)
Set the transmission ratio selector accordingly.
2)
Parameter only appears with "WAY", "-WAY", "ncSLL", and "-ncLL"
3)
If used, the value on the actuator must correspond to the set range of stroke on the lever arm.
Carrier must be set to the value of the actuator travel or, if this value is not scaled, to the next larger scale value.
See also
Commissioning (Page 107)
8.2.2 Overview of application parameters 6 to 55
Introduction
These parameters are used to configure the following additional functions of the positioner:
● Setpoint preparation
● Actual value preparation
● Binary signal processing
● Tight closing function
● Limit detection
Note
Factory-set parameter values are printed in bold in the following table.
Overview
Parameter Function Parameter values Unit
6.SDIR Setpoint direction
Rising riSE
Falling FALL
7.TSUP Setpoint ramp up Auto / 0 ... 400 s
8.TSDO Setpoint ramp down 0 ... 400 s
Parameter assignment
8.2 Tabular overview of the parameters
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 135

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
