Parameter Function Parameter values Unit
9.SFCT Setpoint function
Linear Lin
Equal percentage 1 : 25 1 - 25
1 : 33 1 - 33
1 : 50 1 - 50
Inverse equal percentage 25 : 1 n1 - 25
33 : 1 n1 - 33
50 : 1 n1 - 50
Freely adjustable FrEE
10.SL0 ...
30.SL20
1)
Setpoint turning point
10.SL0 At 0 % 0 ... 100.0 %
11.SL1 .... 5 % ...
29.SL19 95 %
30.SL20 100 %
31.DEBA Deadband of closed-loop controller Auto / 0.1 ... 10.0 %
32.YA Start of manipulated variable limit 0.0 ... 100.0 %
33.YE End of the manipulated variable limit 0.0 ... 100.0 %
34.YNRM Standardization of manipulated variable
To mechanical travel MPOS
To flow FLoW
35.YDIR Direction of action of manipulated variable for display and position feedback
Rising riSE
Falling FALL
36.YCLS Tight closing/fast closing with manipulated variable
None no
Tight closing Up uP
Tight closing Down do
Tight closing Up and Down uP do
Fast closing Up Fu
Fast closing Down Fd
Fast closing Up and Down Fu Fd
Tight closing Up and fast closing Down uP Fd
Fast closing Up and tight closing Down Fu do
37.YCDO Value for fast closing/tight closing Down 0.0 ... 100.0 %
38.YCUP Value for fast closing/tight closing Up 0.0 ... 100.0 %
Parameter assignment
8.2 Tabular overview of the parameters
SIPART PS2 with PROFIBUS PA
136 Operating Instructions, 05/2019, A5E00127926-AC
