Siemens SIPART PS2 User Manual

See also
Overview of device components (Ex) (Page 29)
4.5 Installing the optional modules
4.5.1 General information about the installation of option modules
WARNING
Use in hazardous area
Risk of explosion.
● Only use equipment that is approved for use in the intended hazardous area and labeled
accordingly.
● Do not use devices that have been operated outside the conditions specified for hazardous
areas. If you have used the device outside the conditions for hazardous areas, make all Ex
markings unrecognizable on the nameplate.
4.5.1.1 Opening the standard and and intrinsically safe version
Introduction
The following option modules are available for the positioner in the standard and intrinsically
safe version:
● Position feedback module 6DR4004-6J (Page 60)
● Alarm module 6DR4004-6A (Page 62)
● Slit initiator alarm module (SIA) 6DR4004-6G (Page 64)
● Mechanical limit switch module 6DR4004-6K (Page 66)
● Internal NCS module (iNCS) 6DR4004-5L (Page 70)
● EMC Filter Module 6DR4004-6F (Page 74)
Installing/mounting
4.5 Installing the optional modules
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 53

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
